VR Cockpit
“Virtual Reality Interactive Flight Simulator”
These Rough CAD drawings show the
potential amount of roll and pitch available in the VR Cockpit Motion
Base System.
Inside of the VR Environment, the rider will be able to feel as if they
are looking out the windscreen of that aircraft and the view out the side
will be as real as being in the actual aircraft. The Cockpit instruments
will change according to the aircraft chosen by the rider.
The VR Cockpit will have the ability to be 'Linked Together' to provide
several units to operate together in a 'Multi-Player' Dog fighting, or
Formation type flight.
The VR Vison will provide a 'Full 360 degree View' so as the rider turns
their heads, so will the view. This will add the next level of realism
and together with the Motion Base, makes the VR Cockpit the newest 'State
of The Art' Flight Simulator. To See more info, Click
Here
Purchase this Flight Sim design complete for $35,000 USD with full design and ownership rights.
Wind system to Produce 20 KW @ 240 Vac
Full system design and spec's
to build production versions of my 20 KW system based on higher wind conditions.
Full rights of use and non-compete from me. You can patent it if you wish.
This system has not been disclosed and as such should be patentable.
This system will produce enough torque to run an 20 kw generator that
can be purchased from several different suppliers (info supplied).
It may produce approx 30 Hp from wind speed of 15 mph and higher.
Designed to be mounted approx 20 feet up on structure and could be easily
adapted to mount on flat roof or low slope roof. System will have very
little maintenance and 20 KW would be approx 3 times what a normal home
would need. Sell the extra power back to the utility company because the
production generator sets will produce very nice Sine Wave power that
the utility company would require. If you choose to produce units for
sale you would own all the rights for the design. After you purchase this
design the system may be produced for under $6000 for quantity and a prototype
for approx $8500. To See more info, Click Here
Purchase this 20KW complete design with use and ownership rights for $
16,500 USD.
Don't even ask for disclosure before purchase. I may disclose some after
a non-refundable 50% deposit.
I will produce a prototype unit for additional $12,500 UD.
Modular Magnetic Motor, geared with higher
moment arm for larger torque for powering steady state projects.
Unique magnetic type motor self-running
geared with longer moment arm from center and high power rare earth magnets
for more torque and long life. My design has a forced rotation away from
cogging effect and tends to steady state operation.
Do not think for even 1 second that it is some kind of perpetual motion
system because it is not. It requires force from the magnets and interaction
of other metals. It will require a starting force as well.
Even rare earth magnets will eventually lose their magnetism and originally
required a huge electric force to become magnets.
I have also overnother problem area of eddy currents where other designs
used magnets working against other magnets and could build large eddy
currents which could stop the rotation or drag it down so no torque was
produced.
One largely overlooked problem is the draining or magnetic flux balancing
when magnets interact with other magnets. Magnets of higher power interacting
with magnets of lower power will tend to overtime balance to have close
to the same power. Any design that uses different power magnets interacting
will surely fail.
My design uses a different system so the actual magnets used for the torque
will stay at full power for as long as possible. They would be easy to
replace with new magnets at some point if needed..
This design is more on the risk side and would only be suited to the owner
that can see the vision for such a design. More work may be needed to
get the most from this system but the principles are very workable.
As you can see in the photos, this is a modular system and easy to just
add additional modules.come a
I designed the modules for easy connections with spline input side and
output side. Just slide the modules together and connect to the output
shaft spline. To See More info, Click Here
Purchase this Modular Magnet Motor complete design with use and ownership
rights for $ 37,000 USD.
Modular Piezo generator can produce 40
to 100 vac and amps from just .3 amps @ 12 vdc
This design produces an amount
of AC voltage with an amount of amps from a modular designed piezo system.
It requires at the most .3 amps @ 12 vdc to operate which can be from
a battery charged by wind or solar.
As you can see it has the ability to add as many piezo elements as needed
so a large number will produce a larger output staying within the bounds
of the input of .3 amps @12 vdc.
Maximun number of piezo elements may be in the hundreds still operating
in the input parameters suggested above.
I have left out the most important component of the system for very good
reason. This design is almost too simple and I am amazed no one has built
this before but they haven't.
The principles are centuries old and with advanced piezo elements it may
become the standard for piezo generators.
It is NOT connected to a huge vibration source and the driving vibration
force will surprise you with it simplicity. To See
More info, Click Here
Purchase this Modular Piezo Generator complete design with use and ownership rights for $ 19,500 USD.
Solar panel design to increase power output from standard solar cells
due to concentrated photon design and system to keep cells cooler
This design is a solar panel that has more concentrated
photons on a set of standard solar cells approx 5” X 5” type
and a system to cool those panels.
Approx 2/3 less cells could be used in the same space to provide approx
1/2 cost savings for solar panels.
Multi layer solar cells are cost prohibitive and at this time are still
only produced for very large commercial systems.
This system can be certified by SRCC and FSEC and sold to all residential
and commercial customers.
As an example this system would use only 10 solar cells 5” X 5”
in a panel 15” X 50” where a standard panel would have used
30 solar cells 5” X 5” in that same 15” X 50” area.
So the solar cells would need to produce more per cell and this is accomplished
by concentrating the photons and cooling the cells.
There are dozens of solar concentrators and this system is different because
it can cool the cells so they don't lose their ability to produce the
full power.
If you concentrate the sun onto a cell it will heat and that increase
in power will be lost so how do we cool them so we can continue to see
the power gain with the sunlight gain?
That will be disclosed after purchase.
To give you an idea of the numbers, a 240 watt panel will have 60 cells
and each will max at 4 watts in standard full sun.
That same cell may produce 6 watts in concentrated sun but would lose
most if heated above the max temp.
Standard panels are approx 40” X 66” in size but a single Cooler
Solar panel would be 15” X 50”.
10 cells of a standard panel would produce 40 watts but
10 cells on our panel would produce maybe 60 watts.
60 standard cells come in at 240 watts but
60 of our cells could come in at 360 watts.
With our cooling design and concentrated sunlight we could possibly produce
50 percent more power overall. To See More info, Click
Here
Purchase this Solar Panel complete design with use
and ownership rights for $ 17,500 USD.
Purchase a prototype for this design for additional $2000 USD.
